| Case Material: | Lexan/ABS/Stainless Steel with protective rubber overmold |
| Dimensions: | 135 x 77 x 48 mm (5.3 x 3.05 x 1.9 in) without Pump 193 x 77 x 56 mm (7.6 x 3.1 x 2.2 in) with Pump |
| Weight: | 409 g (14.4 oz) typical, without Pump 511 g (18.0 oz) typical, with Pump |
| Display/Readout: | Color Graphic Liquid Crystal Display |
| Power Source/Run Times: | Rechargeable, Extended-Range Lithium-ion Battery Pack (36 hours) without Pump Rechargeable, Extended-Range Lithium-ion Battery Pack (20 hours) with Pump Replaceable AA Alkaline Battery Pack (10.5 hours) without Pump |
| Operating Temperature Range: | -20 ºC to 55 ºC (-4 ºF to 131 ºF) |
| Operating Humidity Range: | 15% to 95% non-condensing (continuous) |
| Certifications: | INGRESS PROTECTION IP64 ANZEx: Ex ia s Zone 0 I; Ex ia s Zone 0 IIC T4 ATEX: Ex ia IIC T4 Ga; II 1G (or Ex d ia IIC T4 Gb IR sensor); Ex ia I; Equipment Group and Category: I M1/II 1G China CPC: Metrology Approval China Ex: Ex ia d I/IIC T4 CMA: Approval for Mining Products; CH4, O2, CO, CO2 CSA: Cl I, Gr A-D T4; Ex d ia IIC T4 EAC: PBExiadI X; 1ExiadIICT4 X IECEx: Ex ia I (Ex ia d I IR sensor); Ex ia IIC T4 Ga; Ex d ia IIC T4 Gb INMETRO: Ex ia IIC T4 Ga KC: Ex d ia IIC T4 KIMM: Ex d ia IIC T4 MDR: Registration of Plant Design; CH4, O2, CO, H2S, NO2 MSHA: 30 CRF, Part 22, Intrinsically safe for methane/air mixtures PA-DEP: BFE 114-08 Permissible for PA Bituminous Underground Mines UL: Cl I, Div 1, Gr A-D, T4; Cl II, Groups F G; Cl l, Zone LEL 0, AEx ia d IIC T4 (or AEx ia d IIC T4 IR sensor |
